Description:
1) Construction
Center Conductor: 1.02mm Bare Copper/Copper Clad Steel
Dielectric: 4.57mm Foam PE
Shield: Bonded Aluminum Foil
Braid Coverage: 60%-95% Aluminum braid
Jelly/APD: Per Customers' Special Requirement
Jacket: 6.91mm PVC
Steel Messenger:1.30/1.83mm
2) Characteristics
Impedance: 75+/-3 Ohm
Velocity of Propagation: 85%
Return Loss: >=20dB
3) Attenunation[@ 68F. (20.)]
5MHz 2.0dB/100 m
55MHz 5.3dB/100 m
211MHz 10.0dB/100 m
270MHz 11.0dB/100 m
300MHz 11.6dB/100 m
330MHz 12.3dB/100 m
400MHz 13.6dB/100 m
450MHz 14.4dB/100 m
550MHz 16.2dB/100 m
750MHz 19.0dB/100 m
870MHz 20.6dB/100 m
1000MHz 22.2dB/100 m
